MAGNA Lifting Products 20 Ton Plain Trolley PTR2000
MAGNA Lifting Products 20 Ton Plain Trolley PTR2000
Couldn't load pickup availability
Details
Details
MAGNA 20 Ton Plain Trolley PTR2000
The MAGNA PTR2000 is the highest capacity plain trolley in the series, offering a massive 20 Ton (44,000 lbs) Working Load Limit. Designed for the most critical heavy lifting tasks, it provides a stable and mobile anchor point on large structural beams in power plants and heavy manufacturing facilities.
Despite its immense capacity, the PTR2000 is designed for smooth operation, utilizing high-strength steel wheels with sealed, permanent lubrication ball bearings. It features a broad adjustment range for wide-flange beams and includes robust anti-drop lugs to ensure absolute safety. This unit is proof tested to 150% of its rated capacity to guarantee performance under extreme conditions.
Features & Benefits
- Maximum Capacity: Safely handles massive loads up to 44,000 lbs (20 Tons).
- Wide Beam Capable: Fits flange widths from 6.0 to 12.0 inches.
- Maintenance Free: Sealed ball bearings ensure longevity and smooth travel.
- Critical Safety: Heavy-duty anti-drop lugs protect against derailment.
- Rigorous Testing: Load tested to 150% of capacity; ANSI/ASME compliant.
Specifications
- Model Number: PTR2000
- Working Load Limit (WLL): 20 Ton (44,000 lbs)
- Trolley Type: Plain (Push)
- Fits Flange Width: 6.0 - 12.0 in.
- Minimum Radius Curve: 157 in.
- Headroom: 18.0 in.
- Net Weight: 593 lbs
Specifications
Specifications
| MAGNA Lifting Products 20 Ton Plain Trolley PTR2000 | |
| APPLICATION | Material Handling |
| Brand | MAGNA Lifting Products |
| CAPACITY | 20 Ton |
| POWER SOURCE | Manual |
| PRODUCT TYPE | Tools/Machinery |
| TOOL SUB-TYPE | Material Handling/Lifting - Trolleys |
| TOOL TYPE | Material Handling/Lifting |
| TROLLEY TYPE | Plain Trolley |
