MetalPro 1/2", 3/4" Round Pipe Die Set MP95P-012
MetalPro 1/2", 3/4" Round Pipe Die Set MP95P-012
Couldn't load pickup availability
Details
Details
The MP95P-012 Round Pipe Die Set is a high-efficiency tooling solution designed to expand the versatility of the MetalPro MP9500 Hydraulic Bender. Engineered for the fabrication of handrails, gates, and utility structures, this set uniquely combines capabilities for 1/2-inch nominal (0.840" OD) and 3/4-inch nominal (1.050" OD) pipe into a single rotating die. This dual-groove architecture allows operators to switch between these common sizes without the downtime associated with full tooling changeovers.
The set operates on a tight 3-inch Centerline Radius (CLR), ideal for creating compact, professional bends in space-constrained environments. Machined from solid billet carbon steel, the dies are rated to withstand the high compressive loads of bending heavy-wall Schedule 80 pipe, ensuring durability and consistent performance. The package includes the Model 9550 Rotating Die, Model 9551 Stationary Die, and Model 9552 Moving Die, forming a complete, matched tribology system for the MP9500.
Features & Benefits
- Dual-Groove Rotating Die: Model 9550 die features precision-machined channels for both 1/2" and 3/4" pipe, doubling operational utility.
- High-Pressure Rating: Specifically engineered to handle the resistance of Schedule 40 and 80 pipe without die deflection.
- Compact Radius: The 3" CLR delivers tight, aesthetically pleasing bends suitable for architectural ironwork.
- Comprehensive Set: Includes all three required components (Rotating, Stationary, and Moving dies) for immediate use.
Specifications
- Compatible Machine: MetalPro MP9500 Hydraulic Bender
- Pipe Capacity: 1/2" and 3/4" Nominal Pipe
- Centerline Radius: 3.0 Inches
- Component Material: High-Grade Carbon Steel
- Die Models Included: 9550 (Rotary), 9551 (Stationary), 9552 (Moving)
Specifications
Specifications
| MetalPro 1/2", 3/4" Round Pipe Die Set MP95P-012 | |
| APPLICATION | Metal Working |
| Brand | MetalPro |
| PRODUCT TYPE | Accessories |
| TOOL SUB-TYPE | Metal Forming - Benders |
| TOOL TYPE | Metal Forming |
