The Mafell Arunda 120B Midi Timber Dovetail Milling Template Set is designed for creating custom wood-to-wood structural timber joints without metal connectors. Tailored for mid-to-large structural timber framing, this system generates precise dovetail tenons and mortises in timber widths from 120 to 200 mm (4-3/4 to 7-7/8 in.) and timber heights from 90 to 300 mm (3-1/2 to 11-13/16 in.). The 120B model includes adjustable fence stops for routing both 90-degree perpendicular cuts and angled joints up to 50 degrees.

Utilizing a powerful router like the Mafell LO 65 Ec, operators can quickly mill precise male and female timber joints on site or in a prefabrication shop. The wedge-shaped dovetail design aligns timbers automatically during installation and delivers strong load capacities. This Midi set comes fully equipped with the tenon and mortise template pair, cutter head, guide ring, depth gauge, extra blades, and a wooden storage box.

Features & Benefits

• Mid-Size Timber Capacity: Handles timber cross sections from 120 x 90 mm up to 200 x 300 mm for timber framing and post-and-beam construction.
• Angled Joint Capability: Adjustable fence stops allow setting joint angles up to 50 degrees in addition to standard 90-degree square joints.
• Hardware-Free Timber Connections: Creates strong, concealed wood-to-wood connections without nails, screws, or steel brackets.
• Replaceable Carbide Inserts: Included dovetail router bit utilizes double-sided reversible blades for long service life and crisp cutting edges.
• Matched Guide Ring System: Precision guide ring guarantees exact tracking against template contours for consistent joint tolerances.
• Included Depth Gauge: Simplifies cutter setup to achieve exact milling depth and secure joint lockup.

What's Included

• (1) Pair of Arunda 120B Templates (1 Tenon Template, 1 Mortise Template)
• (1) Dovetail Router Cutter with Reversible Blades
• (1) Guide Ring
• (1) Setting Gauge
• (2) Pairs of Reversible Blades
• (1) Wooden Storage Box

For larger timber cross sections, select the Arunda 160B Midi (160 to 300 mm width). For smaller timber sizes, select the Arunda 80B Midi (80 to 140 mm width) or Arunda 50B Midi (45 to 80 mm width).
