Jet L100-25WO-100 1/4-Ton Hand Chain Hoist with 100 ft. Lift & Overload Protection 101244
Jet L100-25WO-100 1/4-Ton Hand Chain Hoist with 100 ft. Lift & Overload Protection 101244
Couldn't load pickup availability
Details
Details
101244, JET L100-25WO-100 1/4-Ton Hand Chain Hoist with 100' Lift & Overload Protection
JET® L-100 Series hand chain hoist integrates safety, durability, and innovation enabling it to operate in the most demanding industrial environments. Safety features such as optional overload protection prevent the hoist from lifting damaging loads beyond its rated capacity. The JET® exclusive innovation showcased in the patented fused brake system reduces maintenance costs and limits downtime. JET® is so confident in the durability of the fused brake design that we back it with an industry-leading lifetime replacement warranty. The JET® L-100 is available in ¼-ton to 20-ton capacities and standard lifts of 10, 15, 20, and 30 feet (custom lifts available). Regardless of how harsh the environment is, the JET® L-100 Series hand chain hoist is engineered to perform.
Features:
- Safety
- Patented Fused Brake Design- Proven durability that increases safety with a lifetime replacement warranty
- Overload Protection- Slip clutch design increases safety by preventing lifting or pulling damaging loads
- Weston Style Dual Pawl Brake System- Double pawl design increases safety
- Alloy Steel Hooks- Industrial-rated hooks rotate 360 degrees for easy rigging. Hooks slowly stretch to indicate an overload situation increasing job site safety
- Durability
- Sealed Ball Bearing Design- Increases efficiency and promotes smooth operation
- Cast Steel Safety Latches- Increased durability with heavy-duty safety latches secured with Allen screws and lock nuts
- Heat Treated Load Plates- Heat treated, case hardened and corrosive resistant coated internal parts extend the life of the hoist in the harshest of environments
- Grade 100 Load Chain- Corrosive resistant grade 100 load chain is stronger than grade 80 load chain extending the life of the hoist
- All Steel Construction- Impact-resistant covers that provide durability and protection
- Compact Design- Smaller body and lightweight design for low headroom applications and use in confined areas
- Standards
- Industry- Complies with OSHA Regulations, ANSI / ASME B30.16, and HST-2 Standards
- Certification- Load tested to 125% of capacity with certificate
Specifications:
- Load Capacity (Tons) 1/4
- Lift (Ft.) 100
- Overload Protection Yes
- Headroom (In.) 9-13/16
- Hand Chain Overhaul (Ft.) to Lift Load 1Ft. 18
- Hand Chain Pull Force (LBF) to Move Load 42
Specifications
Specifications
| Jet L100-25WO-100 1/4-Ton Hand Chain Hoist with 100 ft. Lift & Overload Protection 101244 | |
| APPLICATION | Concrete / Wood Working / Metal Working |
| BRAND COMPATIBILITY | JET |
| Brand | Jet |
| POWER SOURCE | Manual |
| PRODUCT TYPE | Tools/Machinery |
| TOOL TYPE | Hoists |
