1017830, Baileigh PF-1850, 220V, 1/4HP, 4-Speed Power Feeder
Safety should always be one of the main concerns when woodworking and a power feeder and a power feed is one of the easiest ways to ensure that you keep your hands away from cutting edges. The PF-1850 power feeder is an all-purpose feeder that may be mounted for use with various fences and wood machinery such as shapers. The PF-1850 is designed to keep your workpiece as stable as possible using our roller spring suspension, that generates friction and pressure on the workpiece. Workpieces with minor variations in thickness of up to 3/4” are easily compensated via a roller spring mechanism.
When mounted with the include universal mount this powerful feeder uses a continuous duty 1/4 horsepower motor provides the feed, ensuring that your feed rate is consistent and reliable. The PF-1850 has 4 speed settings can easily be changed depending on your requirements.
Specifications:
- Item Number PF-1850
- Shipping Weight 73lbs
- Speeds 20, 26, 33, 43 fpm
- Power 220V Single Phase
- Horse Power 1/4
- Weight (lbs) 80 lbs
- Rotation Forward and Reverse
- Rollers 3
- Roller Diameter 3-1/8"
- Roller Width 1-3/16"
- Roller Travel 3/4"
- Shipping Dimensions (Inches) 23x23x11
* specifications subject to change without notice.
Specifications
Specifications
| Baileigh PF-1850; 220V 1? 1/4HP 4 Speed Gear Driven Power Feeder 1017830 | |
| APPLICATION | Wood Working |
| BRAND COMPATIBILITY | Baileigh |
| Brand | Baileigh |
| HORSEPOWER | 1/4 HP |
| POWER SOURCE | Electric - Corded |
| PRODUCT TYPE | Tools/Machinery |
| TOOL SUB-TYPE | Work Holding - Power Feeders |
| TOOL TYPE | Work Holding |
| VARIABLE SPEED | Yes |
| VOLTAGE | 208V-240V 1Ph |
